Woodward 8440-2116 IKD1M Module

Woodward 8440-2116 IKD1M Technical Specifications
Brand: Woodward (Woodward, Inc.)
Model: 8440-2116 (IKD1M)
Part Number: 8440-2116
Product Name: Digital I/O Expansion Module (IKD1M)
Country of Origin: Germany
HS Code: 85371011 (Industrial control electronic modules)
Dimensions: 168 mm (L) × 128 mm (W) × 51 mm (H)
Weight: Approx. 360 g

Power Supply: 12/24 VDC (6–36 VDC), max. 3 W consumption
Input (DI): 8 × galvanically isolated discrete inputs; 6–32 VDC range, 6.8 kΩ resistance
Output (DO): 8 × Form C potential-free relay outputs; 2 AAC @250 VAC, 2 ADC @24 VDC
Communication: Isolated CAN bus (100 VAC continuous insulation, 1000 VAC test for ≤5s)
Environmental:- Operating Temp.: -20°C to +70°C
Storage Temp.: -30°C to +80°C
Humidity: Up to 95% RH (non-condensing)
Protection: IP20
