3382 Triconex High Precision Analog Output Module

TRICONEX 3382 Product Introduction
Brand: Triconex (Schneider Electric)
Model: 3382
Product Name: High Precision Analog Output Module
Origin: United States
HS Code: 85389000
Dimension: 342 mm × 31 mm × 262 mm
Weight: 0.51 kg
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Rated Supply Voltage: Backplane 5 V DC
Rated Operating Current: 440 mA @ 5 V DC
Relative Humidity: 5% to 95%, non-condensing

Ingress Protection: IP20 for cabinet installation
Triple redundant high precision 4–20 mA output
Lower signal drift and better linearity
Advanced load and wiring fault diagnosis
Supports HART communication for smart valve positioners
Front panel LED indicators for run and fault
Supports hot swap in redundant safety rack
SIL 3 safety certification
Compatible with Tricon v9 processor series
Supports automatic and manual channel calibration
Compliant with IEC 61508 and ISA S84 standards
FAQ for TRICONEX 3382
Q1: What is the main advantage of 3382 compared with 3381?
A1: 3382 provides higher output accuracy, lower drift and enhanced fault detection for critical modulating safety control loops.
Q2: Can 3382 output 0-10V voltage signals?
A2: No, this module only supports 4–20 mA current output.
Q3: Can we replace 3381 directly with 3382 without logic modification?
A3: Hardware replacement is possible, but channel configuration and calibration need to be verified in the Tricon programming software.
