3381 Triconex Analog Output Module

TRICONEX 3381 Product Introduction
Brand: Triconex (Schneider Electric)
Model: 3381
Product Name: Analog Output Module
Origin: United States
HS Code: 85389000
Dimension: 342 mm × 31 mm × 262 mm
Weight: 0.50 kg
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Rated Supply Voltage: Backplane 5 V DC
Rated Operating Current: 430 mA @ 5 V DC
Relative Humidity: 5% to 95%, non-condensing
Ingress Protection: IP20 for cabinet installation

TMR triple redundant analog output architecture
Output signal range 4–20 mA
Built-in output circuit and load fault detection
Supports HART pass-through for valve positioners
Front panel status LED indicators
Supports hot swap in redundant rack configuration
SIL 3 applicable with approved configuration
Output voting ensures accurate control value
Supports offline channel calibration function
Compliant with IEC 61508, CE and UL standards
FAQ for TRICONEX 3381
Q1: Can 3381 be used for safety shutdown valve control?
A1: It can provide modulating 4-20mA control for control valves. On-off ESD shutdown valves normally use digital output modules such as 3201.
Q2: Will 3381 output hold the last value on communication loss?
A2: The output behavior (hold last value or fail-safe) is defined by the safety logic configuration.
Q3: Is field calibration required after module replacement?
A3: After swapping the module, channel calibration verification is recommended to guarantee output accuracy.
