3351 Triconex Enhanced Analog Input Module

TRICONEX 3351 Product Introduction
Brand: Triconex (Schneider Electric)
Model: 3351
Product Name: Enhanced Analog Input Module
Origin: United States
HS Code: 85389000
Dimension: 342 mm × 31 mm × 262 mm
Weight: 0.49 kg
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C

Rated Supply Voltage: Backplane 5 V DC
Rated Operating Current: 410 mA @ 5 V DC
Relative Humidity: 5% to 95%, non-condensing
Ingress Protection: IP20 for cabinet installation
Multi-channel TMR analog input for 4–20mA
Improved loop fault detection algorithm
Supports HART communication pass through
High resolution analog-to-digital conversion
Front panel LED for module and channel health
Supports hot swap operation
SIL 3 capable for safety instrumented functions
Compatible with Tricon v9 rack and main processor
Supports remote sensor diagnostics
Compliant with IEC 61508 and CE requirements
FAQ for TRICONEX 3351
Q1: What is the difference between 3351 and 3301?
A1: 3351 is an enhanced version with upgraded diagnostic logic and better signal stability for dense analog I/O projects.
Q2: Can 3351 and 3301 be mixed in the same Tricon rack?
A2: Yes, they can coexist in the same rack as long as firmware and chassis version match the system requirement.
Q3: Does 3351 support redundant transmitter connection?
A3: Redundant transmitters are configured in safety logic software; the module itself receives one 4-20mA signal per channel.
