3201 Triconex Digital Output Module

TRICONEX 3201Product Introduction
Brand: Triconex (Schneider Electric)
Model: 3201
Product Name: Digital Output Module
Origin: United States
HS Code: 85389000
Dimension: 342 mm × 31 mm × 262 mm
Weight: 0.51 kg
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Rated Supply Voltage: Backplane 5 V DC, field 24 V DC
Rated Operating Current: 440 mA @ 5 V DC
Relative Humidity: 5% to 95%, non-condensing

Ingress Protection: IP20 for cabinet installation
Triple redundant digital output channels
De-energize to trip safety design
Each channel supports solenoid and relay load driving
Built-in output circuit fault diagnosis
Front panel LED indicators for channel run and fault
Supports hot swap in qualified redundant rack
SIL 3 capable with correct configuration
Backplane galvanic isolation
Supports offline channel testing function
Compliant with IEC 61508 and ISA S84 standards
FAQ for TRICONEX 3201
Q1: Is 3201 energize-to-trip or de-energize-to-trip?
A1: It follows de-energize-to-trip design. When safety trip occurs, the output turns off to execute shutdown action.
Q2: Can 3201 directly drive large high-power loads?
A2: It is designed for low-power solenoid and relay coils. High-power equipment needs external intermediate relays.
Q3: Can we perform forced output on 3201 during maintenance?
A3: Force function is available in programming software, but strict safety lockout and permit procedures are required before forcing any safety output.
