TRICONEX 3006 Product Introduction
Brand: TRICONEX
Model: 3006
Product Name: Chassis Expansion Interface Module
Country of Origin: USA
HS Code: 85389000
Dimensions: 311 mm × 194 mm × 32 mm
Weight: 0.88 kg
Operating Temperature: 0 ℃ ~ +60 ℃
Storage Temperature: -40 ℃ ~ +85 ℃
Supply Voltage: 5 V DC backplane
Working Current: 0.4 A
Characteristics: Tricon backplane bus extension; supports connection between main rack and expansion racks; bus fault detection; hot-swappable; maintain TMR redundancy on extended I/O loops.
TRICONEX 3006 FAQ
Q1: What is the function of TRICONEX 3006?
A1: It connects the main controller rack with expansion I/O racks to expand I/O capacity.
Q2: Is the safety level still SIL3 after expansion?
A2: The whole system can still maintain SIL3 when configured correctly.
Q3: Can multiple expansion racks be cascaded?
A3: The maximum number of expansion racks is limited by Tricon system specifications.
3006 TRICONEX Chassis Expansion Interface Module
The TRICONEX 3006 is a backplane expander or interface module for Tricon chassis. It realizes data bus extension and signal interconnection between the main rack and extension I/O racks, expanding the quantity of I/O points of the Tricon safety system.
