2381 TRICONEX Analog Output Module

TRICONEX 2381 Analog Output Module Product Introduction
Brand: TRICONEX (Schneider Electric);
Model: 2381;
Product Name: Analog Output Module;
Dimensions: 315mm × 170mm × 48mm;
Weight: Approximately 1.14kg;
Place of Origin: USA;
HS Code: 85371011;
Operating Temperature: 0°C ~ +60°C;
Storage Temperature: -40°C ~ +85°C;

Relative Humidity: 5% to 95% RH, non-condensing;
Rated Voltage: 24V DC;
Working Current: Max 0.64A;
Power Consumption: 12.6W;
Input: Safety analog command input from Tricon backplane bus;
Output: Multi-channel 4-20mA analog output, loop fault alarm output;
Mounting Type: Tricon chassis rack mounting;
Protection Class: IP20;
Features: TMR triple redundant analog output, per-channel loop diagnosis, hot swappable, overcurrent protection, signal isolation;
Functions: Convert digital safety commands to 4-20mA analog signals, drive field valve positioners and analog indicators, monitor output loop health, report wiring and circuit faults.
