2292 TRICONEX Digital Output Module

TRICONEX 2292 Digital Output Module Product Introduction
Brand: TRICONEX (Schneider Electric);
Model: 2292;
Product Name: Digital Output Module;
Dimensions: 312mm × 170mm × 47mm;
Weight: Approximately 1.12kg;
Place of Origin: USA;
HS Code: 85371011;
Operating Temperature: 0°C ~ +60°C;
Storage Temperature: -40°C ~ +85°C;

Relative Humidity: 5% to 95% RH, non-condensing;
Rated Voltage: 24V DC logic power, field output 24-48V DC;
Working Current: Max 0.68A;
Power Consumption: 13W;
Input: Safety control command input from backplane bus;
Output: Multi-channel digital safety output, circuit fault alarm output;
Mounting Type: Tricon rack slot mounting;
Protection Class: IP20;
Certifications: TÜV SIL3, CE, UL, ATEX;
Features: TMR triple voting output, per-channel circuit diagnosis, hot swappable, short-circuit protection, high safety integrity;
Functions: Execute safety shutdown commands, drive field solenoid valves and safety relays, output status feedback, monitor output circuit health, fault alarm for safety actuation loops.
