Eaton XVS-440-57MPI-1-10 Operator Panel

Eaton XVS-440-57MPI-1-10 Product IntroductioBrand Eaton
Model XVS-440-57MPI-1-10
Order Number 139968 (catalog number)
Product Name XVS-400 Series 5.7-inch Infrared Touch HMI Operator Panel with MPI/Profibus Interface
Country of Origin United States
Customs HS Code 8537109000
Dimensions
– Front dimensions: 212 mm (W) × 156 mm (H)
– Panel cut-out depth: 55 mm
– Overall dimensions (approx.): 212 × 156 × 55 mm (W×H×D)

Weight
Approx. 1.4 kg (3.1 lbs)
Operating Temperature
0°C to +50°C
– Storage temperature: -20°C to +60°C
– Humidity: 10–90% RH (non-condensing)
Input Specifications
– Power supply: 24 V DC SELV (Safety Extra Low Voltage)
– Voltage range: 20.4–28.8 V DC (effective); 19.2–30.0 V DC (with ripple)
– Maximum power consumption: 19 W
– Typical power consumption: 12 W
– Input current (max @24 V DC): 790 mA
Output & Interfaces
– Display: 5.7-inch color CSTN LCD; 320 × 240 (QVGA) resolution; 115 × 86 mm active area
– Touch technology: Infrared (IR); 47×31 logic channels; anti-reflective laminated safety glass
– Communication ports:- 1 × 10/100Base-TX Ethernet (RJ45)
– 1 × RS-232 (9-pin SUB-D)
– 1 × MPI/Profibus-DP interface
– 1 × USB 2.0 Host; 1 × USB 1.1 Device
– External memory: 1 × CompactFlash (CF) Type I/II slot
– Memory: 64 MB DRAM; 1.5 MB Flash; 32 KB NVRAM
– Protection: Front panel IP65; certified to UL 60950-1, CSA C22.2 No. 60950-1, IEC/EN 61131-2, CE
Practical Application Cases
1. Manufacturing Automation: Deployed on assembly lines, packaging machines, and material handling equipment for real-time machine control, parameter setting, and production monitoring.
2. Food & Beverage Processing: Used in bottling, mixing, and packaging systems to manage process parameters, ensure hygiene compliance, and support reliable operation in washdown environments.
3. Industrial Machinery: Integrated with CNC machines, textile equipment, and printing presses for operator control, fault diagnostics, and production data visualization.
4. Water & Wastewater Systems: Implemented in pump stations and treatment facilities to monitor flow, pressure, and valve status, supporting remote and local process management.
5. Building Automation: Utilized in HVAC control, energy management systems, and facility automation for intuitive monitoring and adjustment of building utilities.
6. Legacy System Modernization: Applied to upgrade older industrial equipment with modern HMI functionality, connecting to legacy PLCs via MPI/Profibus interfaces.
