XV-102-D0-57TVR-10 EATON Touch HMI Operator Panel

Eaton XV-102-D0-57TVR-10 Product Description & Technical Specifications
Brand Eaton
Model XV-102-D0-57TVR-10
Order Part Number 142530
Product Name Touch HMI Operator Panel
Place of Origin Czech Republic
Customs HS Code 85371090

Dimensions
Front: 170 mm (W) × 130 mm (H); Panel cut-out: 164 mm × 124 mm; Depth: 136 mm
Weight Approx. 0.54 kg (net)
Operating Temperature 0°C to +50°C (non-condensing)
Storage Temperature -20°C to +60°C
Humidity 5–95% RH, non-condensing
Supply Voltage 24 V DC (nominal); 20.4–28.8 V DC range
Input Current Max 1.5 A (inrush for 2s); typical 0.8 A
Power Consumption Max 12 W
Display 5.7″ TFT color LCD; VGA 640 × 480 resolution; 64K colors; LED backlight (dimmable)
Touch Technolog 4-wire resistive touch sensor
Processor & Memory 800 MHz RISC CPU; 64 MB onboard RAM; SD card slot for expansion
Operating System Windows CE 5.0

Communication Interfaces
1.1 × Ethernet 10/100Base-TX (RJ45)
2. 1 × RS-232 (9-pin DSUB)
3.1 × RS-485 (9-pin DSUB)
4. 1 × CANopen
5. 1 × USB 2.0 Device/Host
Key Features & Characteristics
1.Fanless, passive cooling for reliable industrial operation
2.Robust resistive touch for use with gloves or wet conditions
3.High-brightness dimmable LED backlight
4.Comprehensive communication for multi-vendor system integration
5.Configurable via Eaton Visual Designer software
6.Hot-swappable SD card for data logging and program transfer
7.LED status indicators for power, communication, and faults
8.Certifications: CE, cULus, UL 508, RoHS, IEC 61000-6-2/4
Applications
Industrial machinery control, manufacturing automation, process monitoring, packaging lines, material handling, and factory HMI/SCADA systems.
