VT-VSPD-1-13/V0 Bosch Rexroth IN STOCK

VT-VSPD-1-13/V0 Bosch Rexroth Product Brief
Brand: Bosch Rexroth
Model: VT-VSPD-1-13/V0
Technical Parameters
Dimensions: Eurocard 3HE×7TE; 100 mm × 160 mm (PCB), overall dimension 115 × 175 × 40 mm
Weight: 0.2 kg
Mounting form: DIN 41494 Eurocard, 64-pin DIN 41612 multi-point connector
Operating supply voltage: 24 VDC (21 V … 30 V)
Max current consumption: 1.5 A; standby current 270 mA; internal fuse 4 A time-delay

Set-point analog input: ±10 V / 0-10 V / 4-20 mA; input resistance >100 kΩ; resolution 5 mV @ ±10 V range
Digital inputs: Logic 0: 0-5 V; Logic 1: 16 V … UB
Digital outputs: Logic 0: 0-5 V; Logic 1: UB-3 V; max load 30 mA, short-circuit protected
Valve drive output: Adjustable constant-current output for single-coil or dual-coil proportional solenoids; max ±2.5 A continuous output
Reference voltage output: ±10 V, 30 mA, short-circuit-proof
Communication: RS232 front-panel interface for BODAC parameter setting; Local-bus, up to 32 amplifier nodes, max bus length 280 m
Scan time of set-point processing: 2 ms
Parameter storage: Non-volatile memory for saving configured parameters
Operating temperature: 0 °C … +55 °C
Storage temperature: -20 °C … +70 °C
Protection class: IP20 (for card inside cabinet)
Main Functions
1. Digital closed-loop constant-current control for proportional valve solenoids (no position feedback)
2. Adjustable rising/falling ramp generator for set-point signal
3. Offset, gain, limit value configurable by PC-BODAC software
4. Local bus interconnection for multi-axis synchronized hydraulic control
5. Diagnostic status output, fault indication
6. Support open-loop and closed-loop control of electro-hydraulic drives
