V7768-320001 GE VME Single Board Computer

GE V7768-320001 Concise Technical Specification
Basic Information
Brand: GE (General Electric Intelligent Platforms)
Model: V7768-320001
Product Name: VME Single Board Computer
Origin: United States
HS Code: 85423190
Dimension: Standard 6U VME single slot, 233mm × 160mm × 24mm
Net Weight: 0.52kg
Electrical & Environmental Parameters
Backplane power supply: 5VDC VME bus input, typical power consumption 8W
Hardware configuration: Intel Core 2 Duo processor, up to 2GB DDR2 memory, CompactFlash storage
Communication interfaces: Dual independent gigabit Ethernet, SATA, USB 2.0, serial COM port
Operating temperature: -20℃ ~ +60℃; storage temperature: -40℃ ~ +85℃
Humidity: 5%–95% non-condensing

Protection grade: IP20 for cabinet rack installation
Certifications: CE, UL industrial EMC and shock resistance compliance
Core Product Characteristics
Fully compliant with VITA 1 VMEbus standard, supports master and slave CPU operation in multi-board rack systems; built-in PCI-to-VME transparent bridge for flexible peripheral expansion; front panel LED indicators display power, network, storage and fault running status; conformal coated circuit board to resist dust, moisture and corrosive industrial gas; standard plug-in slot design supports hot-swap maintenance without full system shutdown; wide operating temperature range adapts to power, offshore and factory harsh environments; rich onboard I/O ports eliminate extra expansion boards for medium-scale control tasks; continuous hardware self-diagnosis detects memory, bus and storage faults automatically.
Wiring Instruction
