PXIe-1095 National Instruments Express Chassis

PXIe-1095 NI Technical Specifications
Brand: National Instruments (NI)
Model: PXIe-1095
Order No.: 783882-01 (standard); 785971-01 (with timing)
Product Name: 18-Slot 3U PXI Express Chassis
Origin: United States
HS Code: 84733080

Dimensions (W×H×D): 445 × 177 × 464 mm (17.54 × 6.97 × 18.25 in)
Weight: 16.0 kg (single PSU); 17.7 kg (dual PSU)
Input: 100–240 VAC, 50/60 Hz, 15–7.5 A; 90–264 VAC operating range
Output: +3.3 V (36–60 A), +5 V, ±12 V; 82 W max per slot
Bandwidth: 24 GB/s (PCIe Gen3)
Cooling: 38 W / 58 W / 82 W software-selectable profiles
Features: Redundant PSU, hot-swap, OCXO timing option, 10 MHz REF I/O, remote inhibit
Application: Aerospace, automotive, semiconductor test, high-speed data acquisition
