IS200TDBSH6A GE Discrete Simplex Terminal Board

GE IS200TDBSH6A Introduction & Technical Specifications
Basic Product Information
Brand: GE (General Electric)
Model: IS200TDBSH6A
Product Name: Discrete Simplex Terminal Board
Origin: United States
HS Customs Code: 85371011 (Industrial control system terminal circuit board)

Physical Parameters
Weight: Approximately 0.43 kg
Structure & Size: Standard rack plug-in PCB structure compatible with GE Mark VI system cabinets. It adopts industrial-grade PCB with conformal coating for protection against moisture, dust and corrosion. Equipped with a 48-point numbered terminal layout and a dedicated multi-core connector port, the compact integrated structure enables neat wiring and saves cabinet installation space, supporting quick on-site installation and replacement.
Core Technical Parameters
Terminal Configuration: 48 numbered signal terminals for centralized field signal wiring
Insulation Performance: Insulation resistance over 100 MΩ at 500 VDC; withstands 1500 VAC RMS voltage for one minute between power and signal pins
Contact Resistance: Typical value less than 8 mΩ for stable signal conduction
Operating Temperature: -20°C to +70°C
Mechanical Life: Long service plug-in cycle for repeated maintenance operations
System Matching: Fully compatible with GE Mark VI turbine control and EX2100 excitation control systems
Performance & Structural Characteristics
This terminal board features high-precision wiring terminals and superior insulation isolation design, effectively preventing signal crosstalk and leakage current to ensure accurate signal transmission. The conformal coated circuit board delivers outstanding adaptability to harsh industrial environments such as power plants with high humidity and dust. The standardized numbered terminal layout simplifies on-site wiring, inspection and maintenance work. With stable conductive performance and strong voltage resistance, it supports long-term continuous system operation. It adopts a rugged industrial structure with low failure rate, requiring minimal daily maintenance and perfectly matching original GE control system hardware standards.
