GE IC755CSW07CDA HMI Technical Specifications
Brand: GE (General Electric, Emerson Automation)
Model: IC755CSW07CDA
Order Number: IC755CSW07CDA
Product Name: QuickPanel+ 7″ Color TFT Multi-Touch Operator Interface Terminal
Country of Origin: USA
HS Code: 8537101190
Dimensions (L×W×D): 192 × 137 × 36 mm (7.56 × 5.39 × 1.42 in)
Weight: 0.8 kg (1.76 lb)
Display: 7″ widescreen TFT LCD, 800 × 480 resolution, LED backlight, projected capacitive 2-point multi-touch
Processor: Intel Freescale i.MX535 1 GHz ARM Cortex‑A8
Memory: 512 MB DDR2 SDRAM; 256 MB SLC NAND Flash; 512 KB battery‑backed SRAM
Operating System: Windows Embedded Compact 7
Input Power: 24 VDC ±20%, 3‑pin Phoenix connector, max. 15 W power consumption
Output/Communication:1 × 10/100 Mbps Ethernet (RJ‑45)
1 × RS‑232/RS‑485 serial port
2 × USB 2.0 Host (Type‑A); 1 × USB 2.0 Device (mini‑B)
Environmental Ratings:Operating Temperature: 0 °C to +55 °C
Humidity: 85% RH non‑condensing
Front Panel Protection: IP65 / NEMA 4X (dustproof, waterproof)
Mounting: Panel mount or VESA 75 compliant bracket mount
