IC754VSL06MTD-KH GE HMI Operator Terminal

GE IC754VSL06MTD-KH
Brand: GE
Model: IC754VSL06MTD-KH
Product Name: QuickPanel View Monochrome Industrial HMI Operator Terminal
Country of Origin: United States
HS Code Reference: 8537109090 (Industrial human-machine interface touch panel for automation control; final classification subject to official customs verification)
Technical Parameters
Overall dimension: 126 mm (Height) × 156 mm (Width) × 70 mm (Depth)
Net weight: 1.16 kg
Power supply: 12–30 V DC, typical power consumption 18 W
Display specification: 5.75-inch FSTN monochrome screen, resolution 320 × 240, up to 256 gray scales, CCFL backlight
Touch type: Analog resistive touch screen

Main processor: Intel XScale PXA255, operating frequency 300 MHz
Memory configuration: 32 MB DRAM, 32 MB non-volatile flash memory, 512 KB battery-backed SRAM for data retention
Communication interfaces: 10Base-T Ethernet port, dual configurable RS232/RS485 serial ports, USB interface
Supported communication protocols: Modbus RTU, Modbus TCP, GE proprietary industrial protocols
Operating ambient temperature: -10 ℃ to +60 ℃
Storage temperature range: -20 ℃ to +70 ℃
Relative humidity: 5% to 85%, non-condensing
Front panel protection rating: IP65 (when installed properly on control cabinet)
Mounting method: Embedded panel cutout installation
Housing material: Flame-retardant engineering plastic
Compliance standards: CE, UL industrial equipment standards
Core functions: Real-time monitoring of field process parameters, touch-based equipment operation control, historical alarm recording, trend data display, remote communication with programmable controllers, local parameter setting and fault status indication
