SAACKE HMI 10i
Brand: SAACKE GmbH
Model: HMI 10i
Order Number: HMI 10i
Product Name: 10-inch Industrial Touchscreen HMI for Combustion Control Systems
Origin: Germany (Bremen, SAACKE Headquarters)
HS Code: 85371090 (Industrial Control Panels & HMIs)

Dimensions:
– Front: 273 mm × 211 mm
– Mounting Cutout: 259 mm × 201 mm
– Depth: 40 mm (excl. connectors)
Weight: Approx. 1.05 kg
Operating Temperature: -20°C to +60°C (extendable to +70°C with cooling)
Storage Temperature: -30°C to +70°C
Supply Voltage: 24 V DC (18–32 V DC range)
Power Consumption: Max. 7 W
Display: 10.4-inch color TFT LCD, 640 × 480 (VGA) resolution
Touchscreen: 4-wire resistive touch
Processor: High-speed ARM Cortex embedded CPU
Memory: 128 MB Flash, 128 MB DDR3 RAM
Communication Interfaces:
– 1 × Ethernet 10/100 Mbps (Modbus TCP/IP)
– 1 × RS-485 (Modbus RTU)
– 1 × CANopen (optional)
– 1 × USB host
Protection Rating: Front IP65, Rear IP20
Certifications: DNV-GL, ABS, CE, cULus
Features:
– Pre-configured for SAACKE SE@VIS / combustion controllers
– Real-time monitoring of flame, temperature, pressure, emissions
– Multi-language support (English, German, Chinese)
– Event logging (>10,000 records) & alarm management
– Built-in self-diagnostics & remote service capability
– Rugged industrial design for harsh environments
Applications:
– Marine & offshore boiler/burner control (commercial ships, LNG carriers)
– Thermal power plants & steam generator systems
– Industrial furnaces, incinerators & thermal oil heaters
– Petrochemical & refinery process burners
– Waste-to-energy & biomass combustion systems
– Food & beverage processing heating systems
– SIL 3 safety-compliant combustion control loops
