ABB DSQC643 3HAC024488-001/01 Digital I/O Panel Board

ABB DSQC643
Brand: ABB
Model: DSQC643
Order Number: 3HAC024488-001/01
Product Name: Digital I/O Panel Board (Safety & Control Module)
Place of Origin: Switzerland
Customs Code: HS 85371090
Dimensions: 280 mm x 203 mm x 27 mm

Weight: 0.4 kg (net)
Temperature: Operating -20°C to +60°C; Storage -40°C to +85°C
Electrical: Supply Voltage 24 VDC; 16 Digital Inputs, 16 Digital Outputs; Isolation 500 V DC; Response Time <1 ms; Protection Class IP20
Key Features: Integrated emergency stop (E-stop) functionality; Channel-wise signal configuration; Compact DIN-rail mounting; Real-time status indication; High noise immunity
Application Cases:
1. Robot Safety Systems: Deployed in ABB IRC5 cabinets to manage safety signals including E-stop, door interlocks, and light curtains, ensuring compliance with ISO 13849-1 (PLd).
2. Machine Tending: Monitors and controls peripheral equipment (grippers, clamps, sensors) for CNC machine-tending robots, enabling safe and automated part loading/unloading.
3. Material Handling: Used in automated storage and retrieval systems (AS/RS) to interface robots with position switches, barcode scanners, and emergency stop loops.
