Bently Nevada 3500/42-01-00 Monitoring Module

Bently Nevada 3500/42-01-00
Brand: Bently Nevada (Emerson)
Model: 3500/42-01-00
Order Number: 3500/42-01-00
Product Name: 4-Channel Proximitor Seismic Monitor / Vibration & Displacement Monitoring Module
Place of Origin: United States
Customs Code: HS 85371090
Dimensions: 232 mm × 172 mm × 58 mm

Weight: 1.4 kg (net)
Temperature: Operating -40°C to +70°C; Storage -40°C to +85°C; Humidity 5%–95% non-condensing
Electrical: Supply 18–32 VDC (nominal 24 VDC); Power consumption ≤7.7 W; 4 differential input channels; Sensitivity 3.94–7.87 mV/μm (vibration/displacement); Isolation 1500 VDC; Frequency range 0–1000 Hz
Key Features: TMR-compatible; real-time vibration/displacement monitoring; dynamic signal analysis; alarm threshold triggering; historical data logging; DIN-rail mounting; compatible with 3500 monitoring systems
Application Cases:
1. Gas & Steam Turbines: Monitors radial vibration, axial thrust, and bearing wear in power generation turbines, triggering alarms and shutdowns to prevent catastrophic failure.
2. Centrifugal Compressors: Tracks shaft vibration and displacement in oil & gas compressors, ensuring stable operation in offshore platforms and refineries.
3. Industrial Pumps & Fans: Monitors imbalance and misalignment in large pumps and fans in chemical and water treatment plants, supporting predictive maintenance.
