Bently Nevada 3500/15 106M2679-01 Power Supply Module

Bently Nevada 3500/15 106M2679-01 Technical Specifications
Brand: Bently Nevada (GE)
Model: 3500/15
Order Number: 106M2679-01
Product Name: 3500/15 Universal AC Power Supply Module
Country of Origin: USA
HS Code: 8537101190

Dimensions (W×H×D): 40 × 205 × 215 mm (1.57 × 8.07 × 8.46 in)
Weight: 1.2 kg (2.65 lb)
Input:- Universal AC: 85–264 VAC RMS, 47–63 Hz, 2.8 A max
Peak AC: 120–373 VAC
Output:- System DC: +5 VDC, +12 VDC, –12 VDC (regulated)
Max Power: 150 W (full rack load)
Redundancy: 1+1 hot‑swap, no interruption on replacement
Environmental Ratings:- Operating Temp: 0 °C to +55 °C
Storage Temp: –30 °C to +65 °C
Humidity: 5%–95% RH (non‑condensing)
Protection: IP20 (front panel)
Key Features:- Half‑height, left‑slot mounting in 3500 rack
“Supply OK” LED status indicator
Overvoltage, overcurrent, and short‑circuit protection
