CC-PAIH01 Honeywell Analog Input Module

Honeywell CC-PAIH01 Product Introduction & Technical Parameters
Brand: Honeywell
Model: CC-PAIH01
Product Name: High-Level Analog Input Module
Dimensions: Approximately 114 mm × 92 mm × 118 mm
Weight: Approx. 0.48 kg
Country of Origin: United States
HS Code: 85371090
Operating Temperature: -40°C to +70°C

Storage Temperature: -40°C to +85°C
Input:
16-channel isolated analog inputs
Supported signal types: 4–20 mA, 0–5 V, 1–5 V
24V DC system power via backplane
Output:
Digital processed data transmitted to the controller backbone
HART communication support for smart field devices
Channel status, fault, and communication diagnostic outputs
Features:
16-bit high-resolution analog-to-digital conversion
Full channel-to-channel and field-to-system isolation
Built-in HART protocol for device configuration and diagnostics
High accuracy and linearity over wide temperature range
Plug-in modular design for easy installation and maintenance
Industrial-grade construction for harsh industrial environments
Compliance with CE, UL, and RoHS standards
LED indicators for real-time module and channel status monitoring
Wide compatibility with Honeywell C200 and C300 controller systems
