BENTLY 3500/15 106M1079-01 DCS Power Module in stock

Technical Parameters of BENTLY 3500/15 106M1079-01 Power Module

1.Basic Information

– Brand: BENTLY (Bently Nevada)

– Model: 3500/15 106M1079-01 (Full-size Power Card, also referred to as the “Large Card”)

– Product Category: Power supply module for BENTLY 3500 condition monitoring system

2.Physical Dimensions & Weight

– Overall Dimensions: The module is a full-size design for the BENTLY 3500 rack, with a height of approximately 254 mm (10 inches), a width of 101.6 mm (4 inches), and a depth of 228.6 mm (9 inches) (specific values are subject to the official BENTLY product manual).

– Net Weight: About 1.8 kg (4 lbs), with a slight deviation depending on the accessory configuration.

3.Electrical Specifications

3.1Input Parameters

– AC Input Voltage Range: 85 VAC to 264 VAC, 50/60 Hz (wide voltage input, adaptable to different regional power grids)

– DC Input Voltage Range (optional): 100 VDC to 300 VDC (for DC power supply scenarios)

– Input Current: Max 3 A (at 115 VAC input); Max 1.5 A (at 230 VAC input)

3.2 Output Parameters

– Main Output Voltage: ±15 VDC (for powering vibration, displacement and other monitoring cards in the 3500 system)

– Auxiliary Output Voltage: +5 VDC (for powering communication and logic control modules)

– Total Output Power: 120 W (supports power supply for multiple modules in large-scale 3500 racks, such as 16-slot racks)

– Output Ripple & Noise: ≤ 50 mV p-p (ensures stable power supply for precision monitoring components)

– Load Regulation: ±0.5% (maintains voltage stability under varying load conditions)

4.Compatibility & Application

– Rack Compatibility: Specifically designed for BENTLY 3500 large racks (16 slots and above), occupying 2 rack slots for installation.

– System Compatibility: Fully compatible with all modules of the BENTLY 3500 monitoring system, including vibration monitoring cards (3500/40), speed monitoring cards (3500/50), and relay output cards (3500/32).

– Application Scenarios: Suitable for power supply of large rotating machinery condition monitoring systems such as gas turbines, steam turbines and generators, which require multi-channel and multi-parameter monitoring.
