AI835A 3BSE051306R1 ABB Module NEW

Technical Specifications of ABB AI835A 3BSE051306R1

1. Brand & Model Overview

The ABB AI835A 3BSE051306R1 is a high-precision analog input module belonging to ABB’s industrial control product line, designed for reliable data acquisition in distributed control systems (DCS) and industrial automation applications.

2. Key Specifications

This module is configured with 8 independent analog input channels, supporting universal signal type detection without hardware reconfiguration; it is compatible with ABB’s AC 800M and S800 I/O systems, featuring hot-swappable functionality for convenient maintenance and system expansion.

3. Dimensions & Weight

The module adopts a standard rack-mount design, with a length of 140 mm, a width of 25 mm, a height of 110 mm; its net weight is 0.3 kg, which fits perfectly into ABB S800 I/O racks and saves installation space in electrical cabinets.

4. Input Parameters

Each input channel supports multiple signal types, including 4-20 mA current signals, 0-10 V voltage signals, thermocouple signals (such as J, K, T, E types) and resistance temperature detector (RTD) signals (such as Pt100); the input resolution is 16 bits, and the measurement accuracy is ±0.1% of the full scale, ensuring high-precision data collection. The input impedance is 250 Ω for current channels and 1 MΩ for voltage channels.

5. Output Parameters

The ABB AI835A 3BSE051306R1 is a dedicated analog input module and does not have a signal output function; the collected data is transmitted to the upper control system through the module’s internal bus.

6. Temperature Range

The operating temperature range of the module is -40°C to +70°C, and the storage temperature range is -40°C to +85°C; it has excellent temperature adaptability and can operate stably in harsh industrial environments with extreme temperature variations.
