ABB PP881-3BSE092978R1 PLC DCS touch screen

ABB PP881-3BSE092978R1 Operator Panel Technical Specifications
Product Overview
The ABB PP881-3BSE092978R1 is a high-performance industrial operator panel designed for demanding automation environments. It features a 12.1-inch color display with a resolution of 1024 x 768 pixels, providing clear visualization and intuitive operation. The panel supports multiple communication protocols, including Ethernet and USB, ensuring seamless integration with various control systems. Its robust construction meets IP66 standards for the front panel, making it suitable for use in harsh industrial conditions.

Brand and Model
The unit is manufactured by ABB, with the model number PP881 and the specific part number 3BSE092978R1.
Display Specifications
The PP881 features a 12.1-inch color LCD display with a resolution of 1024 x 768 pixels, offering high clarity and visibility in industrial settings. The display supports touchscreen operation for user-friendly interaction.
Dimensions
The operator panel has a compact design with approximate dimensions of 320 mm in width, 245 mm in height, and 65 mm in depth, allowing for flexible installation in control cabinets or on machine panels.

Weight
The unit weighs approximately 2.8 kg, making it lightweight yet sturdy enough for industrial applications.
Input Specifications
Input capabilities include a touchscreen interface for user input, along with various communication inputs such as Ethernet and USB for data exchange and configuration.
Output Specifications
Output features include Ethernet and USB connectivity for communication with other devices and control systems, enabling efficient data transfer and system integration.
Environmental and Mechanical Ratings
The front panel of the PP881 is rated IP66, providing protection against dust and water ingress, suitable for harsh industrial environments. The overall construction ensures durability and reliable performance in demanding conditions.
