Bently Nevada 3500/01-01 Module

Product Introduction & Technical Specifications
Brand: Bently Nevada
Model: 3500/01-01
Origin: United States
HS Code: 9031809090
Product Name: Bently Nevada 1900/65A Vibration Monitoring System Module
Dimensions: Standard rack-mount module, 19-inch rack compatible, width 48.26 mm (1U height), depth 220 mm, length 177.8 mm
Weight: Net weight 0.85 kg, gross weight 1.1 kg (with standard packaging)
Operating Temperature: -40°C to +85°C (-40°F to +185°F),
storage temperature -55°C to +100°C (-67°F to +212°F)

Input:
Accepts signals from Bently Nevada proximity probes (7200, 3300, 3500 series), velocity transducers, and accelerometers;
input signal range:
0 to 25 mm/s (peak velocity), 0 to 500 µm (peak-to-peak displacement), 0 to 10 g (peak acceleration);
input impedance:
1 MΩ, differential input configuration for anti-interference
Output:
4-20 mA analog output (isolated, 0-20 mA / 4-20 mA configurable), 2 relay contact outputs (SPDT, 250VAC/30VDC, 5A rating), MODBUS RTU communication output (RS485 interface), alarm status digital output

Features:
Dedicated module for continuous vibration monitoring of rotating machinery (turbines, compressors, pumps, motors) in industrial plants
Supports real-time measurement of shaft vibration, bearing vibration, displacement, and speed parameters
Built-in signal conditioning, filtering, and alarm threshold calibration functions; 2-stage alarm (warning & danger) settings
High anti-electromagnetic interference capability, compliant with industrial EMC standards (IEC 61000)
Isolated input/output design to avoid ground loop issues; plug-and-play installation for 19-inch rack systems
Wide power supply compatibility: 24 VDC (18-32 VDC range), low power consumption (≤ 5 W)
Compatible with Bently Nevada 3500, 1900 monitoring system frameworks, supports remote configuration and status diagnosis via software
