Allen-Bradley 2711P-RDT12C Color Touch Display Module

Allen-Bradley 2711P-RDT12C Product Introduction & Technical Parameters
Brand: Allen-Bradley (Rockwell Automation)
Model: 2711P-RDT12C (PanelView Plus 1250)
Product Name: Color Touch Display Module / HMI Operator Interface
Dimensions: 363 mm (W) × 282 mm (H) × 70 mm (D)
Weight: Approx. 2.3 kg (5 lbs)
Country of Origin: United States
HS Code (Customs Code): 8537109060

Temperature Parameters:
Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
Relative Humidity: 5–95% non‑condensing
Input:
Power Input: 85–264V AC (47–63 Hz) or 18–32V DC
Operator Input: Analog resistive touchscreen (10 g actuation force)
Communication Input: Ethernet (EtherNet/IP), RS‑232, USB 2.0
Output:
– Display Output: 12.1‑inch TFT color LCD, 800 × 600 (SVGA) resolution
– Display Brightness: 300 cd/m² (typical)
– Communication Output: EtherNet/IP, Modbus TCP, DF1 protocol support
– Status Indicators: Green COMM LED, Red fault LED

Features:
12.1‑inch color TFT LCD with 18‑bit color depth
Analog resistive touchscreen supports glove operation
Dual Ethernet ports for high‑speed network connectivity
Built‑in USB 2.0 and RS‑232 for device configuration and data transfer
IP65 / NEMA 4X/12/13 front‑panel protection (indoor use)
Shock and vibration resistance per MIL‑STD‑810F
CCFL backlight with minimum 50,000‑hour service life
Plug‑and‑play module for PanelView Plus 1000/1250 systems
CE, UL, and RoHS compliant
Discontinued (as of September 30, 2022) but fully serviceable
